10-60 m²

100-600 ft²

15 - 60 m²

100 - 600 ft²

3 x ¾" tweeter

4 x 1 ½" full-range

4 x 4" woofer

12 speaker drivers

2 x 1" tweeter

4 x 2.5" full-range

2 x 3"" mid-range

1 x 5.25" mid-range + 1 x 1"" tweeter for custom made coaxial centre speaker

2 x 6.5" woofer custom made

3 x 50 W class D for tweeter

4 x 50 W class D for full-range

4 x 50 W class D for woofer

Total: 550 W

12 power amplifiers

10 x 60 watts amplifiers for center channel, left/right/upfiring/side firing outputs

2 x 100 watts amplifiers for bass outputs

Total: 800 W

32 - 22,000 Hz

28 Hz - 23,000 Hz

100 dB SPL

86 dB SPL

94 dB SPL

Dolby Atmos

Dolby TrueHD

Acoustic Placement Settings

Thermal Protection

Adaptive Bass Linearization

Integrated 7.1.4 Dolby Atmos decoding and custom-tuned post-processing with proprietary True Image up- / downmixing algorithm.

Advanced Bass management system

Adaptive Bass Linearization

Thermal protection

Dolby Atmos supporting

Dolby Digital 5.1

Dolby Digital plus 7.1

PCM 7.1 multichannel

Dolby Atmos supporting:

Dolby Digital TrueHD

Dolby Digital plus 7.1 (including DD5.1)

Dolby Atmos, Dolby MAT

PCM 7.1 multichannel

MPEG-2 AAC

MPEG-4 HE-AAC

Presets available and fully customisable through the Bang & Olufsen App

Presets available and fully customisable through the Bang & Olufsen App

112 dB SPL

Automated speaker setup with external microphone:

Speaker level and distance

Speaker role

Speaker position compensation from 30 – 10.000Hz

Room resonance compensation from 30 – 200Hz
